PP Pleated High Flow Filter Cartridge for Pentair Aqualine Replacement
This is the high flow filter cartridge to replace Pentair Aqualine high flow filter cartridge.
The large diameter with larger filtration area reduces the number of filter cartridges and the dimension of housing required.
BENEFITS
•Economical design,more cost advantage
•Higher dirt holding capability,longer service life
•Different application requirement by designing different layers for the filter structure
•Nominal micron rating and absolute micron rating are available
APPLICATIONS
• Sea water desalination, Pre RO desalination
• Food and beverage
• Microelectronics
• Oil&chemical
• Machinery and equipment
• Power plant water treatment
• Steel mill water treatment
PRODUCT SPECIFICATIONS
Outside Diameter | 6.75 inch(172mm) |
Inside Diameter | 2.99 inch(76mm) |
Filter Media | Polypropylene (PP) |
Removal Rating ( µm ) | 0.5, 1,3 5,10,20,40,50,70, 100 |
Length ( " ) | 40（1016mm),60(1589mm) |
Seal Material | EPDM,Buna-N |
Maximum Operating Temperature | Pleated PP: 82°C |
Maximum Operation Differential Pressure | 35 Psid |
